Model |
NVR301-04LB-W |
Video/Audio Input |
IP Video Input |
4-ch |
Network |
Incoming Bandwidth |
40Mbps |
Outgoing Bandwidth |
40Mbps |
Remote Users |
128 |
Protocols |
P2P, UPnP, NTP, DHCP, PPPoE |
Video/Audio Output |
HDMI/VGA Output |
HDMI: 1920x1080p /60Hz, 1920x1080p /50Hz, 1600x1200 /60Hz, 1280x1024 /60Hz, 1280x720 /60Hz, 1024x768 /60Hz VGA: 1920x1080p /60Hz, 1920x1080p /50Hz, 1600x1200 /60Hz, 1280x1024 /60Hz, 1280x720 /60Hz, 1024x768 /60Hz |
Recording Resolution |
1080p/960p/720p/D1/2CIF/CIF |
Audio Output |
1-ch, RCA |
Synchronous Playback |
4-ch |
Corridor Mode Screen |
3/4 |
Decoding |
Decoding format |
Ultra 265/H.265/H.264 |
Live view/ Playback |
1080p/960p/720p/D1/2CIF/CIF |
Capability |
4 x 1080P@20, 4 x 720P@30 |
Hard Disk |
SATA |
1 SATA interface |
Capacity |
Up to 8TB for each HDD |
External Interface |
Network Interface |
1 RJ45 10M/100M self-adaptive Ethernet Interface |
USB Interface |
Rear panel:2 x USB2.0 |
Wi-Fi |
Frequency |
2.4GHz |
Transmission Rate |
150Mbps |
Wireless Standards |
IEEE 802.11b/g/n |
Wireless Range |
280m(open environment) |
General |
Power Supply |
12V DC Power Consumption: ≤ 9 W( without HDD ) |
Working Environment |
-10°C ~ + 55°C ( +14°F ~ +131°F ), Humidity ≤ 90% RH(non-condensing) |
Dimensions(W×D×H) |
205mm ×228mm ×47mm (8.1" × 9.0"×1.9") |
Weight ( without HDD ) |
≤ 0.98Kg(2.16lb) |
Model |
IPC2122SR3-F40W-D |
Sensor |
1/2.7", 2.0 megapixel, progressive scan, CMOS |
Lens |
4.0mm@F1.8 |
DORI Distance |
Lens |
Detect(m) |
Observe(m) |
Recognize(m) |
Identify(m) |
4mm |
60 |
24 |
12 |
6 |
6mm |
90 |
36 |
18 |
9 |
Angle of view(H) |
86.5° |
Angle of View (V) |
44.1° |
Angle of View (O) |
106.4° |
Adjustment angle |
Pan: 0°~360° |
Tilt: 0°~90° |
Rotate: 0°~360° |
Shutter |
Auto/Manual, 1/6~1/100000 s |
Minimum Illumination |
Colour: 0.01 Lux (F1.8 AGC ON) 0 Lux with IR on |
Day/Night |
IR-cut filter with auto switch (ICR) |
Digital noise reduction |
2D/3D DNR |
S/N |
>52dB |
IR Range |
Up to 30m (98 ft) IR range |
Defog |
Digital Defog |
WDR |
DWDR |
